Building workflows / Tools

Tools

Let an LLM call your functions mid-run — look something up, hit an API, take an action — and fold the result into its answer.

An LLM is fluent with language but blind to your data and the outside world. Tools fix that: you hand the model a set of functions it can call partway through an answer — look up a record, hit an API, run a calculation — and it weaves the results back into its response. You decide what each tool can do; the model decides when to reach for it.

How the loop works

When an LLM node has tools, the model can pause mid-answer and call one. Your handler runs, returns a result, and the model picks up where it left off with that result in hand — calling more tools if it needs to, until it has a final answer. Wayflow runs that whole back-and-forth for you.

Define a tool

A tool is three things: a description, a set of typed arguments, and a handler — the function that does the work. Reach for defineTool (from wayflow/runtime):

tools.ts ts
const getWeather = defineTool({
  description: 'Look up the current weather for a city.',
  args: { city: 'string' },
  handler: async ({ city }) => {
    const res = await fetch('https://example.com/weather?city=' + city)
    return res.json()
  },
})

The description and the argument names are what the model reads to decide when and how to call the tool — so write them like you’re explaining the function to a teammate. The handler receives the typed arguments and returns whatever the model should see back.

Make it available

A tool has two halves, and they can live in different places. The handler runs with the runtime, so on your server you register the whole tool:

server.ts ts
const runtime = createRuntime({
  handlers: { llm: createLLMHandler(provider) },
  tools: { getWeather },
})

The editor only needs the tool’s name and description to list it in a node’s Tools field — never the handler, which may hold secrets. So on the client you declare the same tool with defineToolMetadata (also from wayflow/runtime) — no handler — and pass it under the same key:

client.ts ts
const getWeather = defineToolMetadata({
  description: 'Look up the current weather for a city.',
  args: { city: 'string' },
})

const editor = createWorkflowEditor(element, {
  tools: { getWeather },
})

The keys match (getWeather), so a tool the author picks in the editor resolves to its handler on your server at run time. (Running the runtime in the browser instead? Then there’s no split — pass the full defineTool tool to both.)

Give a node access

Open an LLM node’s Tools field in the config panel and pick the tools it may call. A node only sees the ones you select, so you can scope each node to exactly what it needs.

The LLM node's Tools field in the config panel, with a couple of tools selected.
Selecting which tools an LLM node is allowed to call, in its config panel.

Keep handlers on your server

A handler can hold secrets and reach private systems, so keep it on your server-side runtime, never in the browser bundle. See Running on a server for the full client/server wiring.

A whole workflow as a tool

A tool doesn’t have to be a single function — you can expose an entire workflow as one, so a model can call another workflow the same way it calls getWeather. See Workflows as tools.
